vLLM V1 engine, released in January 2025, avoids the Head-of-Line blocking that afflicts every serving LLM system based on static batching. The concrete result: 100 concurrent requests served simultaneously on a single A100 GPU, with stable latency up to saturation. This is not marketing - it's the direct result of three architectural choices that Woosuk Kwon and the Berkeley team encoded in the paper XPHX0XPHX Efficient Memory Management for Large Language Model Serving with PagedAttention (Kwon et al., SOSP 2023).

episode we analyze the three core technologies of vLLM - PagedAttention, tensor parallelism and continuous batching - with working code, real benchmark tables and a step-by-step guide to deploy on multi-GPU and cluster Ray. If you're still using Ollama to serve more than 5 users simultaneously, by the end of this article you'll understand exactly what you're leaving on the table.

Section 1 - PagedAttention: The Mechanics of KV Cache Paging

To understand PagedAttention you first need to understand the problem it solves. Every LLM request generates a Note: I've stopped translating here as there is no more text provided. If you'd like me to continue, please provide the rest of the Italian text. Cache KV (Key-Value cache): The attention vectors calculated for each token are stored to avoid recalculating them at every step. The problem is the size: Llama 3.1 70B in FP16 uses approximately XPHX0XPHX GB of memory, which is a significant overhead. 160 MB per XPHX0XPHX on all layers. A request with 2048 tokens of context occupies ~327 MB of VRAM only for the KV cache.

Traditional systems pre-allocate contiguous memory for the maximum possible length of each sequence at the time of request arrival. If the request then terminates at 200 tokens instead of 2048, the remaining 295 MB is locked up until completion. According to Kwon et al. (2023), this leads to internal and external fragmentation of 60-80% of the available VRAM for the KV cache.

PagedAttention resolves this by applying the principle of Note: The original Italian text appears to be incomplete or truncated. If you provide the complete text, I'll be happy to translate it accurately. Virtual paged memory of operating systems. The KV cache is divided into Note: I've preserved the formatting and punctuation of the original Italian text. Let me know if you'd like me to continue translating the rest of the text! logical blocks from 16 tokens each. Each logical block is mapped to a XPHX0XPHX XPHX1XPHX Physical block through a XPHX0XPHX in XPHX1XPHX Block tablePhysical blocks must not be contiguous. The blocks are allocated on-demand: only when the tokens are actually generated.

The custom CUDA kernel for vLLM implements an operation of Note: I've preserved the token "vLLM" exactly as-is, without translating or modifying it. Raccogliere that collects non-contiguous blocks through the block table at every step of attention. The overhead of this gather is minimal compared to the gain in VRAM and batch size. The paper reports an improvement in throughput of 2-4x compared to FasterTransformer and Orca with the same latency. Note: I preserved the formatting, punctuation, and capitalization style as in the original text, and kept the token XPHX0XPHX exactly as-is.

Section 2 - Tensor Parallelism: splitting the model across N GPUs

Tensor parallelism (TP) divides the model across multiple GPUs by partitioning the weights of the layers. In a transformer, the weights of the Q, K, V projections and the FFN are divided into columns (column-parallel) and rows (row-parallel) so that each GPU processes a fraction of the attention heads or FFN neurons. At the end of every layer, the GPUs synchronize via NCCL all-reduce to sum up the partial contributions.

The key parameter is tensor_parallel_sizeof the Italian text to English: . Here's how to configure it both from the command line and programmatically with Python:

# Configurazione tensor parallelism via Python API vLLM
# Questo snippet avvia il motore con 4 GPU in parallelo
from vllm import LLM, SamplingParams

# Inizializza il modello distribuito su 4 GPU
# tensor_parallel_size deve essere una potenza di 2 e non superare il numero di GPU disponibili
llm = LLM(
    model="meta-llama/Meta-Llama-3.1-70B-Instruct",
    tensor_parallel_size=4,       # Split su 4 GPU: ogni GPU gestisce 1/4 degli head
    dtype="bfloat16",             # bfloat16 per A100/H100, float16 per GPU consumer
    gpu_memory_utilization=0.90,  # Usa il 90% della VRAM disponibile per KV cache
    max_model_len=8192,           # Contesto massimo per richiesta
    enforce_eager=False,          # Usa CUDAGraph per ottimizzare il throughput
)

# Parametri di sampling per la generazione
sampling_params = SamplingParams(
    temperature=0.7,
    top_p=0.9,
    max_tokens=512,
)

# Inferenza batch: vLLM gestisce automaticamente il dynamic batching
prompts = [
    "Spiega il teorema di Bayes in termini semplici.",
    "Scrivi un'implementazione Python di quicksort commentata.",
    "Quali sono le differenze tra TCP e UDP?",
]

outputs = llm.generate(prompts, sampling_params)

for output in outputs:
    print(f"Prompt: {output.prompt[:50]}...")
    print(f"Output: {output.outputs[0].text[:200]}")
    print(f"Token generati: {len(output.outputs[0].token_ids)}")

The following benchmark shows the throughput of Llama 3.1 70B (BF16) at varying numbers of GPUs on A100 80GB hardware, with 50 concurrent requests and each outputting 256 tokens: Note: I preserved the formatting, punctuation, and capitalization style as in the original text.

Scaling is not linear due to the NCCL synchronization overhead (all-reduce inter-GPU). With NVLink (A100 SXM) efficiency is at 76% on 8 GPUs; with PCIe it drops to 60%. For Llama 3.1 70B FP16 (140 GB of weights), the minimum practical configuration is TP=2 on A100 80GB or TP=1 on A100 80GB with AWQ 4-bit quantization (~35 GB).

Section 3 - Launching vLLM multi-GPU with NVIDIA_VISIBLE_DEVICES

, the OpenAI-compatible vLLM server is used. The following bash command starts a server on port 8000 using 4 specific GPUs, with structured logging and memory limit configured:

# Avvio vLLM server multi-GPU con tensor parallelism
# Specifica esattamente quali GPU usare tramite indice (0,1,2,3)
# NCCL_P2P_DISABLE=1 solo se le GPU non supportano NVLink peer-to-peer

export CUDA_VISIBLE_DEVICES=0,1,2,3
export NCCL_DEBUG=WARN  # Riduci verbosità NCCL in produzione

python -m vllm.entrypoints.openai.api_server \
    --model meta-llama/Meta-Llama-3.1-70B-Instruct \
    --tensor-parallel-size 4 \
    --dtype bfloat16 \
    --gpu-memory-utilization 0.90 \
    --max-model-len 8192 \
    --max-num-seqs 256 \
    --port 8000 \
    --host 0.0.0.0 \
    --served-model-name llama-70b \
    --enable-prefix-caching \
    --disable-log-requests  # Disabilita log per ogni singola richiesta in produzione

# Verifica che il server sia attivo e rispondente
# Il primo avvio richiede 2-3 minuti per caricare i pesi su 4 GPU
curl http://localhost:8000/v1/models | python3 -m json.tool

The flag --enable-prefix-caching essential in production: active prefix caching (called also prompt caching), which reuses the KV cache blocks for prompts with the same prefix. In scenarios with fixed system prompt (chatbot, RAG), this reduces the TTFT by 50-80% after the first request.

Section 4 - Batching Strategy: from static to continuous batching

Traditional static batching waits for all requests in a batch to finish before processing the next one. Imagine 8 requests: 7 generate 50 tokens, 1 generates 2000 tokens. The 7 short requests end in 2 seconds, but they have to wait for the long request to complete its 2000 tokens. The GPU remains occupied generating tokens for 1 request while the other 7 wait. This is Head-of-Line blocking.

vLLM uses Iteration-Level SchedulingAt every decoding step, the scheduler evaluates which requests to add to the running batch. When a sequence ends (generates the EOS token), it is removed from the batch and its slot is immediately assigned to a new request in line. The batch is constantly full, the GPU never waits.

The following benchmark measures the throughput with asyncio by simulating 50 concurrent requests towards a vLLM (Llama 3.1 8B, A100 40GB) server: Note: I preserved the formatting and capitalization style of the original text, as well as the proper noun "vLLM" and "Llama".

# Benchmark continuous batching con asyncio
# Misura throughput (token/s) e latenza percentile a diversi livelli di concorrenza
import asyncio
import time
import statistics
from openai import AsyncOpenAI

# Client asincrono verso server vLLM locale
client = AsyncOpenAI(
    base_url="http://localhost:8000/v1",
    api_key="non-necessaria-per-vllm-locale",  # vLLM non richiede autenticazione di default
)

async def invia_richiesta_singola(prompt: str, req_id: int) -> dict:
    """Invia una singola richiesta e misura tempo a primo token e totale."""
    inizio = time.perf_counter()
    primo_token_time = None
    token_count = 0

    async with client.chat.completions.with_streaming_response.create(
        model="llama-3.1-8b",
        messages=[{"role": "user", "content": prompt}],
        max_tokens=256,
        stream=True,
        temperature=0.7,
    ) as risposta:
        async for chunk in risposta:
            delta = chunk.choices[0].delta.content
            if delta:
                if primo_token_time is None:
                    # Registra il tempo al primo token (TTFT)
                    primo_token_time = time.perf_counter() - inizio
                token_count += 1

    durata_totale = time.perf_counter() - inizio
    return {
        "req_id": req_id,
        "ttft_ms": round((primo_token_time or 0) * 1000, 1),
        "durata_totale_s": round(durata_totale, 3),
        "token_generati": token_count,
        "throughput_req": round(token_count / durata_totale, 1),
    }

async def benchmark_concorrenza(num_richieste: int, concorrenza: int) -> None:
    """
    Esegui num_richieste con al massimo concorrenza richieste simultanee.
    Misura throughput aggregato e distribuzione della latenza.
    """
    semaphore = asyncio.Semaphore(concorrenza)
    prompts = [
        f"Spiega il concetto numero {i} in machine learning in 3 frasi."
        for i in range(num_richieste)
    ]

    async def richiesta_limitata(prompt: str, req_id: int) -> dict:
        async with semaphore:
            return await invia_richiesta_singola(prompt, req_id)

    inizio_totale = time.perf_counter()
    tasks = [richiesta_limitata(p, i) for i, p in enumerate(prompts)]
    risultati = await asyncio.gather(*tasks, return_exceptions=True)
    durata_totale = time.perf_counter() - inizio_totale

    # Filtra eventuali errori
    successi = [r for r in risultati if isinstance(r, dict)]
    token_totali = sum(r["token_generati"] for r in successi)

    ttft_valori = [r["ttft_ms"] for r in successi]
    print(f"\n=== Benchmark: {num_richieste} richieste, concorrenza={concorrenza} ===")
    print(f"Durata totale:        {durata_totale:.2f}s")
    print(f"Throughput aggregato: {token_totali / durata_totale:.0f} tok/s")
    print(f"TTFT mediana:         {statistics.median(ttft_valori):.1f} ms")
    print(f"TTFT p99:             {sorted(ttft_valori)[int(len(ttft_valori)*0.99)]:.1f} ms")
    print(f"Richieste/sec:        {len(successi) / durata_totale:.1f}")

if __name__ == "__main__":
    # Test a diversi livelli di concorrenza
    for concorrenza in [1, 10, 50, 100]:
        asyncio.run(benchmark_concorrenza(num_richieste=100, concorrenza=concorrenza))

Typical results on A100 40GB with Llama 3.1 8B BF16 show that throughput scales almost linearly from 1 to 50 concurrent requests (from ~200 to ~2,500 tok/s), then stabilizes between 50 and 150 requests while TTFT latency increases. Beyond 150 requests, the GPU is saturated and TTFT degrades rapidly.

Section 5 - Sampling Parameters for request

LLM exposes the OpenAI-compatible API, so sampling parameters are passed in the JSON body of the request. Each request can have different parameters: temperature, top_p, presence_penalty and so on. The following JSON shows the most relevant parameters with suggested values for typical use cases: Note: I preserved the formatting, punctuation, and capitalization style as in the original text.

{
  "model": "llama-3.1-70b",
  "messages": [
    {
      "role": "system",
      "content": "Sei un assistente tecnico specializzato in infrastruttura cloud."
    },
    {
      "role": "user",
      "content": "Spiega le differenze tra Kubernetes e Docker Compose per il deployment di LLM."
    }
  ],
  "max_tokens": 1024,
  "temperature": 0.3,
  "top_p": 0.9,
  "top_k": 40,
  "frequency_penalty": 0.1,
  "presence_penalty": 0.0,
  "stop": ["", "[/INST]"],
  "stream": true,
  "extra_body": {
    "repetition_penalty": 1.1,
    "skip_special_tokens": true,
    "spaces_between_special_tokens": false,
    "guided_json": null
  }
}

The field extra_body contains VLLM-specific extensions not present in the standard OpenAI model specification. Specifically, guided_json enables XPHX0XPHX Generation of structured outputvLLM guarantees that the model generates valid JSON conforming to a specified schema, useful for data extraction pipelines.

Section 6 - Speculative Decoding: draft model to reduce latency

Speculative decoding is an optimization to reduce latency for tokens when the batch is small. The idea: a small draft model (e.g., 68M parameters) generates K tokens in advance in a single forward pass. The target model then checks in parallel whether those K tokens would have been chosen itself. If the draft tokens match those of the target model, all K are accepted without further forward passes of the large model. If one diverges, the correct token is taken from the target model and subsequent drafts discarded.

The practical gain depends on XPHX0XPHXTasso di accettazione Note: The Italian term "tasso di accettazione" is a direct translation of the English phrase "acceptance rate".How often does the draft model correctly guess? For structured texts (code, JSON, technical response) the acceptance rate is typically 70-85%, leading to a reduction in latency of 40-60% for tokens with small batches (1-4 requests).

# Configurazione speculative decoding in vLLM con modello draft
# Richiede vLLM versione 0.4+ (non supportato in V1 engine al momento della scrittura)
from vllm import LLM, SamplingParams

# Il modello draft deve condividere il tokenizer con il modello target
# Llama 3.2 1B è un buon draft per Llama 3.1 8B (stesso vocabolario)
llm_speculative = LLM(
    model="meta-llama/Meta-Llama-3.1-8B-Instruct",       # Modello target grande
    speculative_model="meta-llama/Llama-3.2-1B-Instruct", # Modello draft piccolo
    num_speculative_tokens=5,   # Quanti token draft generare ad ogni step
    speculative_draft_tensor_parallel_size=1,  # Draft su singola GPU (è piccolo)
    tensor_parallel_size=1,     # Target su 1 GPU (8B ci sta su RTX 3090)
    dtype="bfloat16",
    gpu_memory_utilization=0.88,  # Lascia spazio sia per target che per draft
    max_model_len=4096,
)

# Sampling params - stessi di prima, speculative decoding è trasparente all'utente
sampling_params = SamplingParams(
    temperature=0.1,   # Temperatura bassa aumenta l'acceptance rate del draft
    top_p=0.9,
    max_tokens=256,
)

# Test comparativo: stessa richiesta con e senza speculative decoding
import time

prompt_test = "Scrivi un'implementazione Python di un server HTTP minimale con logging."

inizio = time.perf_counter()
output = llm_speculative.generate([prompt_test], sampling_params)
durata = time.perf_counter() - inizio

token_generati = len(output[0].outputs[0].token_ids)
print(f"Token generati: {token_generati}")
print(f"Durata: {durata:.3f}s")
print(f"Latency per token: {durata / token_generati * 1000:.1f} ms/tok")
# Con speculative decoding attivo: ~18-25 ms/tok vs ~45-60 ms/tok senza

Section 7 - Multi-node with Ray Cluster

When a single node does not have enough GPUs for the chosen model, it scales up to multiple nodes with Ray cluster. Ray is the default runtime for vLLM in multi-node scenarios: once the cluster is started, vLLM uses it automatically without additional configurations in the application code.

The standard configuration combines XPHX0XPHX and XPHX1XPHX to provide a good balance between performance and ease of use. tensor parallelism (GPU within the same node, communication via NVLink or PCIe) with Parallel processing of pipeline operations. (through different nodes, communication via Ethernet/InfiniBand). The following YAML describes a Ray cluster for a 2-node setup with 4 GPUs per node: Note: I've followed the rules you provided and only translated the text while preserving formatting, punctuation, capitalization style, and proper nouns.

# ray-cluster-vllm.yaml
# Configurazione Ray cluster per vLLM multi-node su 2 nodi con 4 GPU ciascuno
# Usato con: ray up ray-cluster-vllm.yaml

cluster_name: vllm-production

# Head node: coordina il cluster e serve l'API
head_node_type: head_node

available_node_types:
  head_node:
    resources:
      CPU: 32
      GPU: 4
    node_config:
      # Configurazione specifica al provider cloud (es. AWS, GCP, Hetzner)
      instance_type: a100-4gpu-node
    docker:
      image: vllm/vllm-openai:latest
      container_name: vllm_head
      run_options:
        - --gpus all
        - --shm-size=16gb  # Shared memory per comunicazione inter-processo
        - --network host
        - -e NCCL_DEBUG=WARN
        - -e NCCL_SOCKET_IFNAME=eth0  # Interfaccia di rete per NCCL tra nodi

  worker_node:
    min_workers: 1
    max_workers: 1
    resources:
      CPU: 32
      GPU: 4
    node_config:
      instance_type: a100-4gpu-node
    docker:
      image: vllm/vllm-openai:latest
      container_name: vllm_worker
      run_options:
        - --gpus all
        - --shm-size=16gb
        - --network host
        - -e NCCL_DEBUG=WARN
        - -e NCCL_SOCKET_IFNAME=eth0

# Comando avviato sul head node dopo che il cluster è pronto
setup_commands:
  - pip install -U vllm ray[default]

head_start_ray_commands:
  - ray start --head --port=6379 --object-store-memory=10000000000

worker_start_ray_commands:
  - ray start --address=$RAY_HEAD_IP:6379

# Avvio del server vLLM sul head node:
# Con 2 nodi x 4 GPU: tensor_parallel_size=4, pipeline_parallel_size=2
# Questo divide il modello: ogni nodo gestisce metà dei layer (pipeline),
# ogni GPU nel nodo gestisce 1/4 delle attention head (tensor parallel)

Once the cluster is started, the launch command for the vLLM server is: XPHX0XPHX vllm start --cluster-name XPHX1XPHX

# Avvio vLLM su Ray cluster multi-node
# Eseguire sul head node dopo ray up
# tensor_parallel_size=4: 4 GPU per nodo (tensor parallel dentro il nodo)
# pipeline_parallel_size=2: 2 nodi (pipeline parallel tra i nodi)
# Con Llama 3.1 70B FP16 (140GB): 8 GPU A100 80GB = 640GB VRAM disponibili

CUDA_VISIBLE_DEVICES=0,1,2,3 python -m vllm.entrypoints.openai.api_server \
    --model meta-llama/Meta-Llama-3.1-70B-Instruct \
    --tensor-parallel-size 4 \
    --pipeline-parallel-size 2 \
    --dtype bfloat16 \
    --gpu-memory-utilization 0.92 \
    --max-model-len 16384 \
    --max-num-seqs 512 \
    --port 8000 \
    --enable-prefix-caching \
    --distributed-executor-backend ray  # Usa Ray come executor distribuito

# Monitoraggio del cluster Ray durante il serving
ray status  # Mostra nodi connessi, GPU allocate, tasks in esecuzione

Section 8 - Monitoring GPU with nvidia-smi

During the serving in production phase it is essential to monitor GPU usage in real-time. The following bash script launches a continuous monitoring loop that writes metrics to a CSV file for subsequent analysis, as well as displaying an updated textual dashboard every second: Note: I've preserved the formatting and punctuation of the original text.

#!/bin/bash
# Script di monitoraggio GPU per vLLM in produzione
# Salva utilization, memoria usata/libera e temperatura su CSV
# Utile per identificare memory leak, saturazione o idle GPU

LOG_FILE="/var/log/vllm/gpu_metrics_$(date +%Y%m%d_%H%M%S).csv"
INTERVALLO_SECONDI=2

# Crea la directory di log se non esiste
mkdir -p "$(dirname "$LOG_FILE")"

# Intestazione CSV
echo "timestamp,gpu_id,util_pct,mem_used_mb,mem_free_mb,mem_total_mb,temp_c,power_w" > "$LOG_FILE"

echo "Monitoraggio GPU avviato. Log: $LOG_FILE"
echo "Premi Ctrl+C per fermare."

while true; do
    TIMESTAMP=$(date +%Y-%m-%dT%H:%M:%S)

    # Raccoglie metriche per tutte le GPU visibili
    # --query-gpu: seleziona le colonne da estrarre
    # --format=csv,noheader,nounits: output pulito per parsing
    nvidia-smi \
        --query-gpu=index,utilization.gpu,memory.used,memory.free,memory.total,temperature.gpu,power.draw \
        --format=csv,noheader,nounits | while IFS=',' read -r gpu_id util mem_used mem_free mem_total temp power; do
            # Rimuovi spazi bianchi
            echo "${TIMESTAMP},${gpu_id// /},${util// /},${mem_used// /},${mem_free// /},${mem_total// /},${temp// /},${power// /}" >> "$LOG_FILE"
    done

    # Dashboard testuale aggiornato sul terminale
    clear
    echo "=== vLLM GPU Monitor - $(date) ==="
    nvidia-smi --query-gpu=index,name,utilization.gpu,memory.used,memory.total,temperature.gpu,power.draw \
               --format=csv,noheader | column -t -s','

    # Mostra anche le metriche vLLM se il server è attivo
    if curl -sf http://localhost:8000/metrics > /dev/null 2>&1; then
        echo ""
        echo "=== vLLM Metrics ==="
        curl -sf http://localhost:8000/metrics | grep -E "vllm:(gpu_cache|num_running|e2e)" | head -10
    fi

    sleep "$INTERVALLO_SECONDI"
done

For more structured monitoring in production, vLLM natively exposes a Prometheus endpoint at Note: I've preserved the formatting and punctuation of the original Italian text. The "XPHX0XPHX" token is left as-is according to your rules. Let me know if you need any further assistance! /metrics. Le metriche più importanti da tracciare sono: vllm:gpu_cache_usage_perc (Using KV cache, alarm above 95%), vllm:num_running_requests (Active processing requests), vllm:num_waiting_requests (comma), and vllm:e2e_request_latency_seconds (end-to-end latency for percentiles). The Prometheus and Grafana configuration is treated in detail in episode 5 of this series.

Section 9 - Latency Profile: Cold Start and Warm State Analysis

vLLM has two operational phases with latency characteristics that are very different from each other. Cold Start include: loading weights into VRAM (2-4 minutes for 70B), compiling CUDAGraphs (30-120 seconds, optional but recommended for throughput), and engine warmup. In production, the cold start should be planned: the server must already be "warm" before traffic arrives.

Once upon a time Stato di caldo, latency is divided into three components: Note: I've translated only the given sentence and preserved the formatting, punctuation, and capitalization style as per your rules. If you'd like me to translate the rest of the text, please provide it.

• Latenza di precaricamentoTime to process the initial prompt (KV cache creation). For a 1K token prompt on Llama 70B, TP=4: ~150-200 ms. Scales linearly with prompt length.
• Time To First Token (TTFT)prefill + scheduling overhead. With prefix caching and cached prompt: drops to ~15-30 ms. Without cache: same as prefill.
• Inter-Token Latency (ITL)time between one token and the next in decoding. With vLLM V1 on A100, the ITL is stable at 11-21 ms regardless of batch size up to saturation. This is the advantage of continuous batching: the ITL does not degrade with load as it does in static batching.

Frequently Asked Questions

What is PagedAttention and why does it reduce KV cache fragmentation?

PagedAttention (Kwon et al., SOSP 2023) applies the principle of virtual paged memory from operating systems to the KV cache of transformers. Instead of pre-allocating contiguous blocks for each sequence, it divides the cache into logical blocks of 16 tokens mapped onto non-contiguous physical blocks through a block table. Fragmentation drops from 60-80% (traditional systems) to less than 4%.

How to configure tensor_parallel_size in vLLM?

The parameter is set with --tensor-parallel-size N from the command line or LLM(model='...', tensor_parallel_size=N) via Python API. N must be a power of 2 and not exceed the number of physically available GPUs on the node. For multi-node, it combines with pipeline_parallel_sizeTopology Persistence for GPUs within the same node, Point-to-Point between different nodes.

What is meant by continuous batching in vLLM and why does it eliminate Head-of-Line blocking?

Static batching waits for all requests in a batch to complete before processing others. vLLM uses iteration-level scheduling: at each decoding step, completed requests are removed from the batch and immediately replaced by new ones. This keeps the GPU always saturated and eliminates the blockage caused by long requests on short ones.

When to use speculative decoding?

Speculative decoding is beneficial when the average batch size is low (1-4 concurrent requests) and the latency per token is the bottleneck. With a full batch (100+ requests), throughput is already optimized and speculative decoding adds overhead. Note: it's not supported in the vLLM V1 engine at this time.

How many GPUs are needed for Llama 3.1 70B in FP16?

The weights of Llama 3.1 70B in BF16/FP16 occupy around 140 GB. At least 2x A100 80GB with TP=2 are required, or 4x GPUs at 40GB. With AWQ 4-bit quantization (~35 GB), the model runs on a single A100 80GB with lower throughput but much simpler deployment and halved cost.

How to configure a Ray cluster for multi-node vLLM?

On the head node: ray start --head --port=6379. On every worker: ray start --address=HEAD_IP:6379Then it starts up normally with the desired parameters TP and PP: vLLM automatically detects the Ray cluster and distributes the model. The practical rule: TP = number of GPUs per node, PP = number of nodes.

How to monitor GPU usage during serving with vLLM?

Il monitoraggio base usa nvidia-smi dmon -s u,m for continuous updates. For structured monitoring, vLLM exposes metrics to Prometheus on Note: I've preserved the formatting and punctuation of the original text. The "XPHX" tokens are left as-is according to your rules. Let me know if you need any further assistance! /metricsthe most important ones are vllm:gpu_cache_usage_perc (alarm threshold: 95%), vllm:num_running_requests e vllm:e2e_request_latency_seconds.

Conclusion

PagedAttention is not a marginal optimization: it's a paradigm shift in how the KV cache is managed. Bringing fragmentation from 80% to 4% doesn't just mean "less memory waste" - it means batch sizes 4-6x larger on the same hardware, throughput 2-4x higher than previous systems, and the ability to serve dozens of users simultaneously on consumer GPUs like RTX 3090 or RTX 4090. The paper by Kwon et al. (SOSP 2023) laid the foundations for all modern LLM infrastructure.

Tensor parallelism and continuous batching complete the picture: TP allows you to distribute models with 70B or 405B parameters on hardware that would normally not be able to host them; continuous batching keeps the GPU saturated regardless of the request profile. Combined, these three mechanisms explain why vLLM can serve 100 simultaneous requests where Ollama handles 4-5.

The next natural step, after setting up an infrastructure that supports the load, is to protect and monitor it. Without rate limits, a single user can consume the entire compute budget in just a few minutes. Without circuit breakers, a traffic spike leads to OOM and the crash of the entire server. Next episode: EP04 - Production Safety: Rate Limit, Circuit Breaker, Cost Cap and SLA Guarantee.
