06 - Anomaly Detection Comportamentale: ML su Log Data

# Feature Engineering per Log di Sicurezza
# File: security_feature_engineer.py

import pandas as pd
import numpy as np
from datetime import datetime, timedelta
from collections import defaultdict

class SecurityFeatureEngineer:
    def __init__(self, window_size_minutes: int = 60):
        self.window_size = window_size_minutes

    def extract_user_session_features(self, logs_df: pd.DataFrame) -> pd.DataFrame:
        """
        Input: DataFrame con colonne [timestamp, user, event_id, host,
                                       src_ip, process_name, logon_type]
        Output: DataFrame con features aggregate per sessione utente
        """
        logs_df['timestamp'] = pd.to_datetime(logs_df['timestamp'])
        logs_df['hour'] = logs_df['timestamp'].dt.hour
        logs_df['day_of_week'] = logs_df['timestamp'].dt.dayofweek
        logs_df['is_business_hours'] = logs_df['hour'].between(8, 18).astype(int)
        logs_df['is_weekend'] = (logs_df['day_of_week'] >= 5).astype(int)

        # Aggregazione per user-window
        features = []

        for user, user_logs in logs_df.groupby('user'):
            # Finestre temporali mobili
            user_logs = user_logs.sort_values('timestamp')

            for i in range(0, len(user_logs), self.window_size):
                window = user_logs.iloc[i:i+self.window_size]
                if len(window) == 0:
                    continue

                feature_row = self._compute_window_features(user, window)
                features.append(feature_row)

        return pd.DataFrame(features)

    def _compute_window_features(self, user: str,
                                   window: pd.DataFrame) -> dict:
        """Calcola features per una finestra temporale."""
        return {
            'user': user,
            'window_start': window['timestamp'].min(),

            # Volume features
            'total_events': len(window),
            'unique_hosts': window['host'].nunique(),
            'unique_processes': window['process_name'].nunique(),
            'unique_src_ips': window['src_ip'].nunique(),

            # Event type distribution
            'logon_events': (window['event_id'] == 4624).sum(),
            'failed_logons': (window['event_id'] == 4625).sum(),
            'logoff_events': (window['event_id'] == 4634).sum(),
            'privilege_use': (window['event_id'] == 4672).sum(),
            'process_creation': (window['event_id'] == 4688).sum(),

            # Temporal features
            'is_business_hours_ratio': window['is_business_hours'].mean(),
            'is_weekend_ratio': window['is_weekend'].mean(),
            'hour_entropy': self._entropy(window['hour']),

            # Logon type distribution
            'interactive_logons': (window['logon_type'] == 2).sum(),
            'network_logons': (window['logon_type'] == 3).sum(),
            'remote_interactive': (window['logon_type'] == 10).sum(),

            # Ratios e derived features
            'failed_logon_rate': (
                (window['event_id'] == 4625).sum() /
                max((window['event_id'] == 4624).sum(), 1)
            ),
            'host_diversity': (
                window['host'].nunique() / max(len(window), 1)
            ),
        }

    def _entropy(self, series: pd.Series) -> float:
        """Calcola l'entropia di Shannon di una serie categorica."""
        if len(series) == 0:
            return 0.0
        counts = series.value_counts(normalize=True)
        return -sum(p * np.log2(p) for p in counts if p > 0)

    def extract_network_features(self, netflow_df: pd.DataFrame) -> pd.DataFrame:
        """Features da NetFlow/zeek logs."""
        netflow_df['timestamp'] = pd.to_datetime(netflow_df['timestamp'])

        features = netflow_df.groupby(['src_ip', pd.Grouper(
            key='timestamp', freq=f'{self.window_size}min'
        )]).agg(
            total_bytes=('bytes', 'sum'),
            total_packets=('packets', 'sum'),
            unique_dst_ips=('dst_ip', 'nunique'),
            unique_dst_ports=('dst_port', 'nunique'),
            connection_count=('dst_ip', 'count'),
            avg_duration=('duration', 'mean'),
            # Beaconing indicator: bassa varianza in intervalli di connessione
            duration_std=('duration', 'std'),
            # Port scanning indicator
            high_port_count=(
                'dst_port',
                lambda x: (x > 1024).sum()
            ),
        ).reset_index()

        # Beaconing score (bassa std = possibile C2)
        features['beaconing_score'] = 1 / (features['duration_std'] + 1)

        # Port scan score
        features['port_scan_score'] = (
            features['unique_dst_ports'] /
            features['connection_count'].clip(lower=1)
        )

        return features

# Isolation Forest per User Behavior Anomaly Detection
# File: isolation_forest_detector.py

from sklearn.ensemble import IsolationForest
from sklearn.preprocessing import StandardScaler
import numpy as np
import pandas as pd
import joblib
from pathlib import Path

class UserBehaviorIsolationForest:
    def __init__(self,
                  contamination: float = 0.05,  # 5% atteso anomalie
                  n_estimators: int = 200,
                  random_state: int = 42):
        self.model = IsolationForest(
            contamination=contamination,
            n_estimators=n_estimators,
            max_samples='auto',
            max_features=1.0,
            random_state=random_state,
            n_jobs=-1
        )
        self.scaler = StandardScaler()
        self.feature_names: list[str] = []
        self.is_fitted = False

    # Feature numeriche usate per il modello
    NUMERIC_FEATURES = [
        'total_events', 'unique_hosts', 'unique_processes', 'unique_src_ips',
        'logon_events', 'failed_logons', 'privilege_use', 'process_creation',
        'is_business_hours_ratio', 'hour_entropy', 'failed_logon_rate',
        'host_diversity', 'interactive_logons', 'network_logons'
    ]

    def fit(self, features_df: pd.DataFrame) -> 'UserBehaviorIsolationForest':
        """Addestra il modello sul comportamento normale."""
        X = features_df[self.NUMERIC_FEATURES].fillna(0)
        self.feature_names = self.NUMERIC_FEATURES

        # Normalizza le features
        X_scaled = self.scaler.fit_transform(X)

        # Addestra Isolation Forest
        self.model.fit(X_scaled)
        self.is_fitted = True

        print(f"Modello addestrato su {len(X)} campioni")
        return self

    def predict(self, features_df: pd.DataFrame) -> pd.DataFrame:
        """Predice anomalie. Ritorna DataFrame con score e label."""
        if not self.is_fitted:
            raise RuntimeError("Modello non addestrato. Chiama fit() prima.")

        X = features_df[self.NUMERIC_FEATURES].fillna(0)
        X_scaled = self.scaler.transform(X)

        # Score: più negativo = più anomalo
        anomaly_scores = self.model.decision_function(X_scaled)
        predictions = self.model.predict(X_scaled)  # 1=normale, -1=anomalia

        result_df = features_df.copy()
        result_df['anomaly_score'] = anomaly_scores
        # Normalizza score in [0, 1] dove 1 = massima anomalia
        score_min = anomaly_scores.min()
        score_max = anomaly_scores.max()
        result_df['anomaly_score_normalized'] = (
            1 - (anomaly_scores - score_min) / (score_max - score_min + 1e-10)
        )
        result_df['is_anomaly'] = predictions == -1
        result_df['anomaly_label'] = predictions

        return result_df

    def fit_predict_with_rolling_baseline(
        self,
        all_features_df: pd.DataFrame,
        training_days: int = 30,
        evaluation_window_days: int = 1
    ) -> pd.DataFrame:
        """
        Addestra su una finestra mobile e predice sulla finestra successiva.
        Simula il deployment rolling in produzione.
        """
        all_features_df = all_features_df.sort_values('window_start')
        all_features_df['window_start'] = pd.to_datetime(all_features_df['window_start'])

        all_results = []
        start_date = all_features_df['window_start'].min()
        end_date = all_features_df['window_start'].max()

        current_date = start_date + timedelta(days=training_days)
        while current_date <= end_date:
            # Training window: ultimi N giorni
            train_start = current_date - timedelta(days=training_days)
            train_mask = (
                (all_features_df['window_start'] >= train_start) &
                (all_features_df['window_start'] < current_date)
            )
            train_df = all_features_df[train_mask]

            # Evaluation window: prossimo giorno
            eval_end = current_date + timedelta(days=evaluation_window_days)
            eval_mask = (
                (all_features_df['window_start'] >= current_date) &
                (all_features_df['window_start'] < eval_end)
            )
            eval_df = all_features_df[eval_mask]

            if len(train_df) < 100 or len(eval_df) == 0:
                current_date += timedelta(days=evaluation_window_days)
                continue

            # Addestra e predice
            model = UserBehaviorIsolationForest()
            model.fit(train_df)
            results = model.predict(eval_df)
            all_results.append(results)

            current_date += timedelta(days=evaluation_window_days)

        return pd.concat(all_results, ignore_index=True) if all_results else pd.DataFrame()

    def save(self, path: str) -> None:
        Path(path).parent.mkdir(parents=True, exist_ok=True)
        joblib.dump({
            'model': self.model,
            'scaler': self.scaler,
            'feature_names': self.feature_names
        }, path)

    @classmethod
    def load(cls, path: str) -> 'UserBehaviorIsolationForest':
        data = joblib.load(path)
        instance = cls()
        instance.model = data['model']
        instance.scaler = data['scaler']
        instance.feature_names = data['feature_names']
        instance.is_fitted = True
        return instance

# Autoencoder per Anomaly Detection
# File: autoencoder_detector.py

import torch
import torch.nn as nn
import numpy as np
import pandas as pd
from torch.utils.data import DataLoader, TensorDataset

class SecurityAutoencoder(nn.Module):
    def __init__(self, input_dim: int, encoding_dim: int = 8):
        super(SecurityAutoencoder, self).__init__()

        # Encoder: comprime l'input in una rappresentazione latente
        self.encoder = nn.Sequential(
            nn.Linear(input_dim, 64),
            nn.ReLU(),
            nn.BatchNorm1d(64),
            nn.Dropout(0.2),
            nn.Linear(64, 32),
            nn.ReLU(),
            nn.BatchNorm1d(32),
            nn.Linear(32, encoding_dim),
            nn.ReLU()
        )

        # Decoder: ricostruisce l'input dalla rappresentazione latente
        self.decoder = nn.Sequential(
            nn.Linear(encoding_dim, 32),
            nn.ReLU(),
            nn.BatchNorm1d(32),
            nn.Linear(32, 64),
            nn.ReLU(),
            nn.BatchNorm1d(64),
            nn.Dropout(0.2),
            nn.Linear(64, input_dim),
            nn.Sigmoid()  # Output normalizzato [0, 1]
        )

    def forward(self, x: torch.Tensor) -> torch.Tensor:
        encoded = self.encoder(x)
        decoded = self.decoder(encoded)
        return decoded

    def encode(self, x: torch.Tensor) -> torch.Tensor:
        return self.encoder(x)

class AutoencoderAnomalyDetector:
    def __init__(self, encoding_dim: int = 8, epochs: int = 100,
                  batch_size: int = 64, learning_rate: float = 1e-3,
                  device: str = 'auto'):
        self.encoding_dim = encoding_dim
        self.epochs = epochs
        self.batch_size = batch_size
        self.learning_rate = learning_rate
        self.device = (
            torch.device('cuda' if torch.cuda.is_available() else 'cpu')
            if device == 'auto' else torch.device(device)
        )
        self.model: SecurityAutoencoder = None
        self.threshold: float = None
        self.scaler = None

    def fit(self, X_normal: np.ndarray) -> 'AutoencoderAnomalyDetector':
        """Addestra l'autoencoder solo su dati normali."""
        from sklearn.preprocessing import MinMaxScaler
        self.scaler = MinMaxScaler()
        X_scaled = self.scaler.fit_transform(X_normal).astype(np.float32)

        input_dim = X_scaled.shape[1]
        self.model = SecurityAutoencoder(input_dim, self.encoding_dim).to(self.device)

        # Training
        dataset = TensorDataset(torch.FloatTensor(X_scaled))
        loader = DataLoader(dataset, batch_size=self.batch_size, shuffle=True)
        optimizer = torch.optim.Adam(self.model.parameters(), lr=self.learning_rate)
        criterion = nn.MSELoss()

        self.model.train()
        for epoch in range(self.epochs):
            total_loss = 0
            for batch in loader:
                x = batch[0].to(self.device)
                optimizer.zero_grad()
                reconstructed = self.model(x)
                loss = criterion(reconstructed, x)
                loss.backward()
                optimizer.step()
                total_loss += loss.item()

            if epoch % 20 == 0:
                avg_loss = total_loss / len(loader)
                print(f"Epoch {epoch}/{self.epochs}, Loss: {avg_loss:.6f}")

        # Calcola threshold come percentile 95 degli errori di ricostruzione
        # sul training set normale
        reconstruction_errors = self._compute_reconstruction_errors(X_scaled)
        self.threshold = np.percentile(reconstruction_errors, 95)
        print(f"Threshold anomalia: {self.threshold:.6f}")

        return self

    def _compute_reconstruction_errors(self, X_scaled: np.ndarray) -> np.ndarray:
        """Calcola errori di ricostruzione elemento per elemento."""
        self.model.eval()
        with torch.no_grad():
            X_tensor = torch.FloatTensor(X_scaled).to(self.device)
            reconstructed = self.model(X_tensor)
            errors = torch.mean((X_tensor - reconstructed) ** 2, dim=1)
        return errors.cpu().numpy()

    def predict(self, X: np.ndarray) -> dict:
        """Predice anomalie e restituisce score e labels."""
        X_scaled = self.scaler.transform(X).astype(np.float32)
        reconstruction_errors = self._compute_reconstruction_errors(X_scaled)

        is_anomaly = reconstruction_errors > self.threshold
        anomaly_score = reconstruction_errors / self.threshold  # Score normalizzato

        return {
            'reconstruction_error': reconstruction_errors,
            'anomaly_score': anomaly_score,
            'is_anomaly': is_anomaly,
            'threshold': self.threshold
        }

# Interpretabilita con SHAP per Anomaly Detection
# File: shap_explainer.py

import shap
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt

class AnomalyExplainer:
    def __init__(self, isolation_forest_model,
                  feature_names: list[str]):
        self.model = isolation_forest_model
        self.feature_names = feature_names
        self.explainer = None

    def fit_explainer(self, background_data: pd.DataFrame) -> None:
        """Inizializza lo SHAP explainer con dati di background."""
        X_bg = background_data[self.feature_names].fillna(0)
        self.explainer = shap.TreeExplainer(self.model)

    def explain_anomaly(self, anomalous_sample: pd.Series) -> dict:
        """Spiega perchè un campione e anomalo."""
        if self.explainer is None:
            raise RuntimeError("Chiama fit_explainer() prima.")

        X = anomalous_sample[self.feature_names].fillna(0).values.reshape(1, -1)
        shap_values = self.explainer.shap_values(X)

        feature_contributions = sorted(
            zip(self.feature_names, shap_values[0]),
            key=lambda x: abs(x[1]),
            reverse=True
        )

        return {
            'top_anomaly_drivers': [
                {
                    'feature': name,
                    'shap_value': float(value),
                    'actual_value': float(anomalous_sample.get(name, 0)),
                    'direction': 'increases_anomaly' if value < 0 else 'decreases_anomaly'
                }
                for name, value in feature_contributions[:5]
            ],
            'explanation': self._generate_natural_language_explanation(
                feature_contributions[:3], anomalous_sample
            )
        }

    def _generate_natural_language_explanation(
        self,
        top_features: list[tuple],
        sample: pd.Series
    ) -> str:
        """Genera una spiegazione in linguaggio naturale."""
        explanations = []
        for feature, shap_val in top_features:
            value = sample.get(feature, 0)
            if feature == 'failed_logon_rate' and value > 0.3:
                explanations.append(
                    f"Tasso di logon falliti anomalmente alto ({value:.1%})"
                )
            elif feature == 'unique_hosts' and value > 5:
                explanations.append(
                    f"Accesso a {int(value)} host distinti (inusuale)"
                )
            elif feature == 'is_business_hours_ratio' and value < 0.2:
                explanations.append(
                    f"Attivita prevalentemente fuori orario lavorativo ({value:.1%})"
                )
            elif feature == 'hour_entropy' and value > 2.0:
                explanations.append(
                    f"Pattern orario molto irregolare (entropia: {value:.2f})"
                )

        return "; ".join(explanations) if explanations else "Pattern comportamentale inusuale rilevato"

# Pipeline completa di produzione
# File: anomaly_detection_pipeline.py

import logging
from dataclasses import dataclass

@dataclass
class AnomalyAlert:
    user: str
    window_start: str
    anomaly_score: float
    reconstruction_error: float
    explanation: str
    top_features: list[dict]
    severity: str

class AnomalyDetectionPipeline:
    def __init__(self,
                  if_model: UserBehaviorIsolationForest,
                  ae_model: AutoencoderAnomalyDetector,
                  feature_names: list[str]):
        self.if_model = if_model
        self.ae_model = ae_model
        self.feature_names = feature_names
        self.explainer = AnomalyExplainer(if_model.model, feature_names)
        self.logger = logging.getLogger(__name__)

    def process_batch(self, features_df: pd.DataFrame,
                       score_threshold: float = 0.7) -> list[AnomalyAlert]:
        """Processa un batch di features e ritorna gli alert."""
        alerts = []

        # Isolation Forest predictions
        if_results = self.if_model.predict(features_df)

        # Autoencoder predictions
        X = features_df[self.feature_names].fillna(0).values
        ae_results = self.ae_model.predict(X)

        # Combina i due modelli con ensemble voting
        for idx, row in if_results.iterrows():
            if_score = row['anomaly_score_normalized']
            ae_score = ae_results['anomaly_score'][idx]

            # Ensemble: media pesata (IF più affidabile su questo tipo di dati)
            ensemble_score = 0.6 * if_score + 0.4 * min(ae_score, 1.0)

            if ensemble_score >= score_threshold:
                # Genera spiegazione SHAP
                try:
                    explanation = self.explainer.explain_anomaly(row)
                except Exception as e:
                    self.logger.warning(f"SHAP explain failed: {e}")
                    explanation = {'explanation': 'N/A', 'top_anomaly_drivers': []}

                severity = self._score_to_severity(ensemble_score)
                alerts.append(AnomalyAlert(
                    user=row.get('user', 'unknown'),
                    window_start=str(row.get('window_start', '')),
                    anomaly_score=round(ensemble_score, 3),
                    reconstruction_error=float(ae_results['reconstruction_error'][idx]),
                    explanation=explanation.get('explanation', ''),
                    top_features=explanation.get('top_anomaly_drivers', []),
                    severity=severity
                ))

        return sorted(alerts, key=lambda a: a.anomaly_score, reverse=True)

    def _score_to_severity(self, score: float) -> str:
        if score >= 0.95:
            return 'critical'
        elif score >= 0.85:
            return 'high'
        elif score >= 0.75:
            return 'medium'
        else:
            return 'low'

# Drift Detection per Anomaly Models
# File: drift_detector.py

from scipy import stats

class ModelDriftDetector:
    def __init__(self, baseline_scores: np.ndarray,
                  drift_threshold: float = 0.05):
        self.baseline_scores = baseline_scores
        self.drift_threshold = drift_threshold

    def check_drift(self, recent_scores: np.ndarray) -> dict:
        """
        Usa Kolmogorov-Smirnov test per rilevare drift nella distribuzione
        degli anomaly score.
        """
        ks_statistic, p_value = stats.ks_2samp(
            self.baseline_scores, recent_scores
        )

        drift_detected = p_value < self.drift_threshold
        severity = 'none'
        if drift_detected:
            if ks_statistic > 0.3:
                severity = 'high'
            elif ks_statistic > 0.15:
                severity = 'medium'
            else:
                severity = 'low'

        return {
            'drift_detected': drift_detected,
            'ks_statistic': float(ks_statistic),
            'p_value': float(p_value),
            'severity': severity,
            'recommendation': (
                'Retraining necessario' if severity == 'high'
                else 'Monitoraggio aumentato' if severity == 'medium'
                else 'Nessuna azione richiesta'
            )
        }

    def detect_false_positive_spike(self, fp_rate_history: list[float],
                                      window: int = 7) -> bool:
        """Rileva spike nel tasso di falsi positivi."""
        if len(fp_rate_history) < window:
            return False

        recent = np.mean(fp_rate_history[-window:])
        historical = np.mean(fp_rate_history[:-window])
        return recent > historical * 2  # FP rate raddoppiato = alert
