07 - OpenCV + PyTorch: Pipeline CV Completa
Computer VisionFoto:Christina MorilloPexels

In Breve

Guida completa a OpenCV + PyTorch: Pipeline CV Completa: architettura, implementazione pratica e best practices per developer e team tecnici.

OpenCV e PyTorch: Pipeline Completa di Computer Vision

OpenCV e PyTorch sono i due pilastri dell'ecosistema computer vision moderno. OpenCV eccelle nell'acquisizione, preprocessing e post-processing delle immagini: operazioni tradizionali, gestione di webcam e video, trasformazioni morfologiche, filtri classici. PyTorch porta il deep learning: reti neurali, GPU computing, training end-to-end. Insieme, formano una pipeline CV completa che va dall'acquisizione raw dei pixel alla predizione intelligente.

In questo articolo costruiremo una pipeline completa di computer vision: dall'acquisizione video con OpenCV, al preprocessing, all'inference con un modello PyTorch/YOLO, fino alla visualizzazione e logging dei risultati. Un sistema production-ready che potete deployare direttamente.

Cosa Imparerai

  • OpenCV fondamentali: lettura immagini/video, spazi colore, operazioni morfologiche
  • Integrazione OpenCV-PyTorch: conversione tensori, pipeline ottimizzata
  • Acquisizione video in tempo reale con buffer management
  • Pre-processing pipeline: resize, normalize, batch preparation
  • Inference ottimizzata: batch processing, async inference
  • Post-processing: NMS, coordinate transformation, annotazione frame
  • Multi-camera pipeline e RTSP stream processing
  • Sistema di logging e alerting per eventi rilevati
  • Ottimizzazione performance: threading, GPU streams, profiling

1. OpenCV Fondamentali per CV Pipeline

1.1 Spazi Colore e Conversioni

Un punto critico spesso trascurato: OpenCV usa il formato BGR per default, mentre PyTorch (e PIL) usano RGB. Confondere i due produce risultati disastrosi: il modello pre-addestrato su immagini RGB ricevera canali invertiti. Sempre convertire!

OpenCV: Operazioni Base
import cv2
import numpy as np
import torch

# ---- Lettura e conversioni ----
def load_image_rgb(path: str) -> np.ndarray:
    """Carica immagine in formato RGB (corretto per PyTorch)."""
    img_bgr = cv2.imread(path)
    if img_bgr is None:
        raise FileNotFoundError(f"Immagine non trovata: {path}")
    return cv2.cvtColor(img_bgr, cv2.COLOR_BGR2RGB)

def bgr_to_torch(img_bgr: np.ndarray) -> torch.Tensor:
    """
    Converte immagine OpenCV BGR in tensor PyTorch normalizzato.
    BGR [H, W, C] uint8 -> RGB [C, H, W] float32 normalizzato [0,1]
    """
    img_rgb = cv2.cvtColor(img_bgr, cv2.COLOR_BGR2RGB)
    tensor = torch.from_numpy(img_rgb).permute(2, 0, 1).float() / 255.0
    return tensor

def torch_to_bgr(tensor: torch.Tensor) -> np.ndarray:
    """
    Converte tensor PyTorch in immagine OpenCV BGR.
    RGB [C, H, W] float32 -> BGR [H, W, C] uint8
    """
    img_rgb = (tensor.permute(1, 2, 0).cpu().numpy() * 255).astype(np.uint8)
    return cv2.cvtColor(img_rgb, cv2.COLOR_RGB2BGR)

# ---- Spazi colore utili ----
def analyze_color_spaces(img_bgr: np.ndarray) -> dict:
    """Analizza l'immagine in diversi spazi colore."""
    return {
        'bgr':  img_bgr,
        'rgb':  cv2.cvtColor(img_bgr, cv2.COLOR_BGR2RGB),
        'gray': cv2.cvtColor(img_bgr, cv2.COLOR_BGR2GRAY),
        'hsv':  cv2.cvtColor(img_bgr, cv2.COLOR_BGR2HSV),
        'lab':  cv2.cvtColor(img_bgr, cv2.COLOR_BGR2LAB),
        'yuv':  cv2.cvtColor(img_bgr, cv2.COLOR_BGR2YUV),
    }

# ---- Operazioni morfologiche ----
def apply_morphology(gray: np.ndarray, operation: str = 'opening',
                     kernel_size: int = 5) -> np.ndarray:
    """
    Operazioni morfologiche per pre/post-processing.
    opening = erosione + dilatazione (rimuove rumore piccolo)
    closing = dilatazione + erosione (chiude piccoli buchi)
    """
    kernel = cv2.getStructuringElement(cv2.MORPH_ELLIPSE, (kernel_size, kernel_size))

    ops = {
        'erode':   cv2.erode(gray, kernel),
        'dilate':  cv2.dilate(gray, kernel),
        'opening': cv2.morphologyEx(gray, cv2.MORPH_OPEN, kernel),
        'closing': cv2.morphologyEx(gray, cv2.MORPH_CLOSE, kernel),
        'gradient': cv2.morphologyEx(gray, cv2.MORPH_GRADIENT, kernel),
        'tophat':  cv2.morphologyEx(gray, cv2.MORPH_TOPHAT, kernel)
    }

    return ops.get(operation, gray)

# ---- Rilevamento contorni e feature classiche ----
def detect_edges_and_contours(img_bgr: np.ndarray) -> tuple:
    """Pipeline classica: blur -> Canny -> contorni."""
    gray = cv2.cvtColor(img_bgr, cv2.COLOR_BGR2GRAY)
    blurred = cv2.GaussianBlur(gray, (5, 5), 0)
    edges = cv2.Canny(blurred, threshold1=50, threshold2=150)

    contours, hierarchy = cv2.findContours(
        edges, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE
    )

    # Filtra contorni per area minima
    significant_contours = [c for c in contours if cv2.contourArea(c) > 500]

    return edges, significant_contours

# ---- Preprocessing per modelli DL ----
def preprocess_for_model(img_bgr: np.ndarray,
                          target_size: tuple[int,int] = (640, 640),
                          mean: list = [0.485, 0.456, 0.406],
                          std: list = [0.229, 0.224, 0.225]) -> torch.Tensor:
    """
    Pipeline completa: BGR immagine -> tensor normalizzato pronto per inference.
    """
    # Letterbox resize (mantiene aspect ratio)
    h, w = img_bgr.shape[:2]
    target_h, target_w = target_size
    scale = min(target_h / h, target_w / w)
    new_h, new_w = int(h * scale), int(w * scale)

    resized = cv2.resize(img_bgr, (new_w, new_h), interpolation=cv2.INTER_LINEAR)

    # Padding per raggiungere target_size
    pad_h = target_h - new_h
    pad_w = target_w - new_w
    padded = cv2.copyMakeBorder(
        resized,
        pad_h // 2, pad_h - pad_h // 2,
        pad_w // 2, pad_w - pad_w // 2,
        cv2.BORDER_CONSTANT, value=(114, 114, 114)
    )

    # BGR -> RGB -> float -> normalize -> tensor
    rgb = cv2.cvtColor(padded, cv2.COLOR_BGR2RGB)
    tensor = torch.from_numpy(rgb).float() / 255.0
    tensor = tensor.permute(2, 0, 1)  # HWC -> CHW

    mean_t = torch.tensor(mean).view(3, 1, 1)
    std_t  = torch.tensor(std).view(3, 1, 1)
    tensor = (tensor - mean_t) / std_t

    return tensor.unsqueeze(0), scale, (pad_w // 2, pad_h // 2)  # batch dim + metadata

2. Acquisizione Video e Webcam

2.1 VideoCapture e Frame Buffer

VideoCapture con Buffer Management e Threading
import cv2
import threading
import queue
import time
from dataclasses import dataclass

@dataclass
class Frame:
    """Wrapper per un frame con metadata."""
    data: np.ndarray
    timestamp: float
    frame_id: int

class ThreadedVideoCapture:
    """
    VideoCapture con lettura in thread separato.
    Previene il drop di frame dovuto al processing lento:
    la GPU che fa inference non blocca la lettura della camera.
    """

    def __init__(self, source, max_buffer_size: int = 5):
        self.cap = cv2.VideoCapture(source)
        if not self.cap.isOpened():
            raise RuntimeError(f"Impossibile aprire: {source}")

        # Ottimizza per latenza bassa
        self.cap.set(cv2.CAP_PROP_BUFFERSIZE, 1)

        self.buffer = queue.Queue(maxsize=max_buffer_size)
        self.stopped = False
        self.frame_id = 0

        # Avvia thread di lettura
        self.thread = threading.Thread(target=self._read_frames, daemon=True)
        self.thread.start()

    def _read_frames(self) -> None:
        """Thread worker: legge frame continuamente."""
        while not self.stopped:
            ret, frame = self.cap.read()
            if not ret:
                self.stopped = True
                break

            frame_obj = Frame(
                data=frame,
                timestamp=time.time(),
                frame_id=self.frame_id
            )
            self.frame_id += 1

            # Scarta frame vecchi se il buffer e pieno
            if self.buffer.full():
                try:
                    self.buffer.get_nowait()
                except queue.Empty:
                    pass

            self.buffer.put(frame_obj)

    def read(self) -> Frame | None:
        """Leggi prossimo frame disponibile."""
        try:
            return self.buffer.get(timeout=1.0)
        except queue.Empty:
            return None

    def get_fps(self) -> float:
        return self.cap.get(cv2.CAP_PROP_FPS)

    def get_resolution(self) -> tuple[int, int]:
        w = int(self.cap.get(cv2.CAP_PROP_FRAME_WIDTH))
        h = int(self.cap.get(cv2.CAP_PROP_FRAME_HEIGHT))
        return w, h

    def release(self) -> None:
        self.stopped = True
        self.cap.release()

    def __enter__(self):
        return self

    def __exit__(self, *args):
        self.release()

3. Pipeline CV Completa: OpenCV + YOLO

Pipeline Production-Ready con Logging e Alerting
import cv2
import torch
import numpy as np
import time
import logging
import json
from pathlib import Path
from datetime import datetime
from dataclasses import dataclass, field
from ultralytics import YOLO

logging.basicConfig(level=logging.INFO,
                    format='%(asctime)s - %(levelname)s - %(message)s')
logger = logging.getLogger(__name__)

@dataclass
class Detection:
    """Singola detection con tutti i metadata."""
    class_name: str
    class_id: int
    confidence: float
    bbox: tuple[int, int, int, int]  # x1, y1, x2, y2
    timestamp: float = field(default_factory=time.time)
    frame_id: int = 0

    def to_dict(self) -> dict:
        return {
            'class': self.class_name,
            'confidence': round(self.confidence, 3),
            'bbox': list(self.bbox),
            'timestamp': self.timestamp,
            'frame_id': self.frame_id
        }

class CVPipeline:
    """
    Pipeline completa Computer Vision:
    Acquisizione -> Preprocessing -> Inference -> Post-processing -> Output
    """

    def __init__(
        self,
        model_path: str,
        source,                          # int (webcam), str (file/RTSP)
        conf_threshold: float = 0.4,
        iou_threshold: float = 0.45,
        target_classes: list[str] | None = None,  # None = tutte le classi
        output_dir: str = 'output',
        save_video: bool = False,
        alert_classes: list[str] | None = None     # classi che triggerano alert
    ):
        self.model = YOLO(model_path)
        self.conf = conf_threshold
        self.iou = iou_threshold
        self.target_classes = target_classes
        self.alert_classes = alert_classes or []
        self.output_dir = Path(output_dir)
        self.output_dir.mkdir(exist_ok=True)

        self.source = source
        self.save_video = save_video

        # Stats
        self.frame_count = 0
        self.total_detections = 0
        self.start_time = None
        self.fps_history = []

    def run(self) -> None:
        """Avvia la pipeline di processing."""
        logger.info(f"Avvio pipeline: source={self.source} modello={self.model.model_name}")

        cap = cv2.VideoCapture(self.source)
        if not cap.isOpened():
            raise RuntimeError(f"Impossibile aprire source: {self.source}")

        # Setup video writer se richiesto
        writer = None
        if self.save_video:
            fps = cap.get(cv2.CAP_PROP_FPS) or 30.0
            w = int(cap.get(cv2.CAP_PROP_FRAME_WIDTH))
            h = int(cap.get(cv2.CAP_PROP_FRAME_HEIGHT))
            timestamp = datetime.now().strftime('%Y%m%d_%H%M%S')
            out_path = str(self.output_dir / f"output_{timestamp}.mp4")
            writer = cv2.VideoWriter(out_path, cv2.VideoWriter_fourcc(*'mp4v'), fps, (w, h))
            logger.info(f"Salvataggio video: {out_path}")

        self.start_time = time.time()
        detection_log = []

        try:
            while True:
                ret, frame = cap.read()
                if not ret:
                    break

                t0 = time.perf_counter()

                # Inference
                detections = self._run_inference(frame, self.frame_count)

                # Visualizzazione
                annotated = self._annotate_frame(frame, detections)

                # Stats overlay
                elapsed = time.perf_counter() - t0
                fps = 1.0 / elapsed if elapsed > 0 else 0.0
                self.fps_history.append(fps)
                annotated = self._add_stats_overlay(annotated, fps, len(detections))

                # Salvataggio
                if writer:
                    writer.write(annotated)

                cv2.imshow('CV Pipeline', annotated)
                if cv2.waitKey(1) & 0xFF == ord('q'):
                    break

                # Logging detections
                for det in detections:
                    detection_log.append(det.to_dict())
                    if det.class_name in self.alert_classes:
                        self._trigger_alert(det)

                self.frame_count += 1
                self.total_detections += len(detections)

        finally:
            cap.release()
            if writer:
                writer.release()
            cv2.destroyAllWindows()

            # Salva log
            log_path = self.output_dir / 'detection_log.json'
            with open(log_path, 'w') as f:
                json.dump(detection_log, f, indent=2)

            self._print_stats()

    def _run_inference(self, frame: np.ndarray, frame_id: int) -> list[Detection]:
        """Esegue YOLO inference su un singolo frame."""
        results = self.model.predict(
            frame, conf=self.conf, iou=self.iou, verbose=False
        )

        detections = []
        for box in results[0].boxes:
            class_name = self.model.names[int(box.cls[0])]

            # Filtra per classi target se specificato
            if self.target_classes and class_name not in self.target_classes:
                continue

            x1, y1, x2, y2 = [int(c) for c in box.xyxy[0]]
            detections.append(Detection(
                class_name=class_name,
                class_id=int(box.cls[0]),
                confidence=float(box.conf[0]),
                bbox=(x1, y1, x2, y2),
                frame_id=frame_id
            ))

        return detections

    def _annotate_frame(self, frame: np.ndarray, detections: list[Detection]) -> np.ndarray:
        """Annota il frame con bounding boxes e label."""
        annotated = frame.copy()
        np.random.seed(42)
        colors = {name: tuple(np.random.randint(50, 255, 3).tolist())
                  for name in self.model.names.values()}

        for det in detections:
            x1, y1, x2, y2 = det.bbox
            color = colors.get(det.class_name, (0, 255, 0))

            cv2.rectangle(annotated, (x1, y1), (x2, y2), color, 2)

            label = f"{det.class_name} {det.confidence:.2f}"
            label_size, _ = cv2.getTextSize(label, cv2.FONT_HERSHEY_SIMPLEX, 0.6, 2)
            cv2.rectangle(annotated,
                         (x1, y1 - label_size[1] - 10),
                         (x1 + label_size[0] + 5, y1), color, -1)
            cv2.putText(annotated, label, (x1 + 2, y1 - 5),
                       cv2.FONT_HERSHEY_SIMPLEX, 0.6, (255, 255, 255), 2)

        return annotated

    def _add_stats_overlay(self, frame: np.ndarray, fps: float,
                            n_detections: int) -> np.ndarray:
        """Aggiunge overlay con statistiche real-time."""
        h = frame.shape[0]
        stats = [
            f"FPS: {fps:.1f}",
            f"Detections: {n_detections}",
            f"Frame: {self.frame_count}",
            f"Avg FPS: {np.mean(self.fps_history[-30:]):.1f}" if self.fps_history else "Avg FPS: -"
        ]

        for i, text in enumerate(stats):
            cv2.putText(frame, text, (10, h - 100 + i * 25),
                       cv2.FONT_HERSHEY_SIMPLEX, 0.6, (0, 255, 0), 2)
        return frame

    def _trigger_alert(self, det: Detection) -> None:
        """Gestisce un evento di alert per classi critiche."""
        logger.warning(f"ALERT: {det.class_name} rilevato con confidenza {det.confidence:.2f} "
                       f"(frame {det.frame_id})")
        # In produzione: invia notifica (email, Slack, webhook)

    def _print_stats(self) -> None:
        """Stampa statistiche finali della sessione."""
        elapsed = time.time() - self.start_time
        avg_fps = self.frame_count / elapsed if elapsed > 0 else 0
        logger.info(f"\n=== Statistiche Pipeline ===")
        logger.info(f"Frame processati: {self.frame_count}")
        logger.info(f"Detections totali: {self.total_detections}")
        logger.info(f"Tempo totale: {elapsed:.1f}s")
        logger.info(f"FPS medio: {avg_fps:.1f}")


# Utilizzo
if __name__ == '__main__':
    pipeline = CVPipeline(
        model_path='yolo26m.pt',
        source=0,           # webcam (o 'video.mp4', 'rtsp://...')
        conf_threshold=0.4,
        target_classes=['person', 'car', 'truck'],
        alert_classes=['person'],
        output_dir='output',
        save_video=True
    )
    pipeline.run()

4. Operazioni OpenCV per Post-Processing

Optical Flow, Background Subtraction, Tracking
import cv2
import numpy as np

# ---- Background Subtraction (MOG2) ----
def setup_background_subtraction():
    """
    MOG2: Mixture of Gaussians per rilevamento movimento.
    Utile come primo filtro prima dell'inference DL.
    """
    subtractor = cv2.createBackgroundSubtractorMOG2(
        history=500,
        varThreshold=50,
        detectShadows=True
    )
    return subtractor

def detect_motion(frame_bgr: np.ndarray, subtractor,
                  min_contour_area: int = 1000) -> list[tuple]:
    """Rileva regioni di movimento nel frame."""
    fg_mask = subtractor.apply(frame_bgr)

    # Cleanup maschera
    kernel = cv2.getStructuringElement(cv2.MORPH_ELLIPSE, (5, 5))
    fg_mask = cv2.morphologyEx(fg_mask, cv2.MORPH_OPEN, kernel)
    fg_mask = cv2.morphologyEx(fg_mask, cv2.MORPH_CLOSE, kernel)

    contours, _ = cv2.findContours(
        fg_mask, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE
    )

    motion_regions = []
    for c in contours:
        if cv2.contourArea(c) >= min_contour_area:
            x, y, w, h = cv2.boundingRect(c)
            motion_regions.append((x, y, x+w, y+h))

    return motion_regions

# ---- Optical Flow (Lucas-Kanade) ----
def compute_sparse_optical_flow(prev_gray: np.ndarray,
                                  curr_gray: np.ndarray,
                                  prev_points: np.ndarray) -> tuple:
    """
    Lucas-Kanade optical flow per tracking di punti specifici.
    Utile per tracking di keypoints rilevati nel frame precedente.
    """
    lk_params = dict(
        winSize=(21, 21),
        maxLevel=3,
        criteria=(cv2.TERM_CRITERIA_EPS | cv2.TERM_CRITERIA_COUNT, 30, 0.01)
    )

    curr_points, status, error = cv2.calcOpticalFlowPyrLK(
        prev_gray, curr_gray, prev_points, None, **lk_params
    )

    good_prev = prev_points[status.flatten() == 1]
    good_curr = curr_points[status.flatten() == 1]

    # Calcola velocità media del movimento
    if len(good_prev) > 0:
        flow_vectors = good_curr - good_prev
        avg_speed = np.mean(np.linalg.norm(flow_vectors, axis=1))
    else:
        avg_speed = 0.0

    return good_curr, good_prev, avg_speed

# ---- CSRT Tracker (più preciso di MOSSE) ----
class ObjectTracker:
    """
    Tracker multi-oggetto per mantenere l'identità degli oggetti
    tra frame consecutivi senza rieseguire l'inference a ogni frame.
    """

    def __init__(self, tracker_type: str = 'CSRT'):
        self.tracker_type = tracker_type
        self.trackers = []  # lista di (tracker, class_name, id)
        self.next_id = 0

    def add_tracker(self, frame: np.ndarray, bbox: tuple, class_name: str) -> int:
        """Aggiunge un tracker per un nuovo oggetto."""
        x1, y1, x2, y2 = bbox
        cv2_bbox = (x1, y1, x2 - x1, y2 - y1)  # formato OpenCV: x, y, w, h

        tracker = cv2.TrackerCSRT_create()
        tracker.init(frame, cv2_bbox)

        obj_id = self.next_id
        self.trackers.append((tracker, class_name, obj_id))
        self.next_id += 1

        return obj_id

    def update(self, frame: np.ndarray) -> list[dict]:
        """Aggiorna tutti i tracker con il nuovo frame."""
        active_objects = []
        failed_trackers = []

        for i, (tracker, class_name, obj_id) in enumerate(self.trackers):
            success, cv2_bbox = tracker.update(frame)

            if success:
                x, y, w, h = [int(v) for v in cv2_bbox]
                active_objects.append({
                    'id': obj_id,
                    'class_name': class_name,
                    'bbox': (x, y, x + w, y + h)
                })
            else:
                failed_trackers.append(i)

        # Rimuovi tracker falliti (indietro per evitare shift indici)
        for i in reversed(failed_trackers):
            self.trackers.pop(i)

        return active_objects

    def clear(self) -> None:
        self.trackers = []

5. Multi-Camera Pipeline e RTSP Stream

Multi-Camera con RTSP e Load Balancing
import cv2
import threading
import queue
import torch
from ultralytics import YOLO
from dataclasses import dataclass

@dataclass
class CameraFrame:
    camera_id: int
    frame: np.ndarray
    timestamp: float

class MultiCameraPipeline:
    """
    Pipeline multi-camera con:
    - Thread separato per ogni camera
    - Coda condivisa per batch inference
    - GPU condivisa tra tutte le camere
    """

    def __init__(self, sources: list, model_path: str, batch_size: int = 4):
        self.sources = sources
        self.model = YOLO(model_path)
        self.batch_size = batch_size
        self.frame_queue = queue.Queue(maxsize=batch_size * 2)
        self.stopped = False

    def _camera_reader(self, camera_id: int, source) -> None:
        """Thread worker per singola camera."""
        cap = cv2.VideoCapture(source)
        cap.set(cv2.CAP_PROP_BUFFERSIZE, 1)

        if isinstance(source, str) and 'rtsp' in source:
            cap.set(cv2.CAP_PROP_FOURCC, cv2.VideoWriter_fourcc(*'H264'))

        while not self.stopped:
            ret, frame = cap.read()
            if not ret:
                logger.warning(f"Camera {camera_id} disconnessa")
                time.sleep(1.0)
                cap = cv2.VideoCapture(source)  # Reconnect
                continue

            frame_obj = CameraFrame(camera_id=camera_id, frame=frame,
                                    timestamp=time.time())

            try:
                self.frame_queue.put(frame_obj, timeout=0.1)
            except queue.Full:
                pass  # Drop frame se la coda e piena

        cap.release()

    def run(self) -> None:
        """Avvia tutti i reader thread e processa batch dalla coda."""
        threads = []
        for i, source in enumerate(self.sources):
            t = threading.Thread(
                target=self._camera_reader, args=(i, source), daemon=True
            )
            t.start()
            threads.append(t)

        logger.info(f"Pipeline avviata: {len(self.sources)} camere")

        batch = []
        while not self.stopped:
            try:
                frame_obj = self.frame_queue.get(timeout=0.5)
                batch.append(frame_obj)

                # Processa batch quando pieno o timeout
                if len(batch) >= self.batch_size:
                    self._process_batch(batch)
                    batch = []

            except queue.Empty:
                if batch:
                    self._process_batch(batch)
                    batch = []

    def _process_batch(self, batch: list[CameraFrame]) -> None:
        """Inference batch su GPU - più efficiente di inference singola."""
        frames = [f.frame for f in batch]

        # Batch inference con YOLO
        results = self.model.predict(
            frames, conf=0.4, iou=0.45, verbose=False
        )

        for frame_obj, result in zip(batch, results):
            n_det = len(result.boxes)
            if n_det > 0:
                logger.info(f"Camera {frame_obj.camera_id}: {n_det} oggetti rilevati")

    def stop(self) -> None:
        self.stopped = True

# Configurazione multi-camera
pipeline = MultiCameraPipeline(
    sources=[
        0,                          # Webcam locale
        'rtsp://192.168.1.100/stream1',  # Camera IP RTSP
        'rtsp://192.168.1.101/stream1',  # Camera IP RTSP 2
        'videos/recording.mp4'      # File video
    ],
    model_path='yolo26m.pt',
    batch_size=4
)
# pipeline.run()

6. Profiling e OpenCV CUDA Accelerated

6.1 PyTorch Profiler per Pipeline CV

Prima di ottimizzare, misura. Il PyTorch Profiler e lo strumento più potente per identificare i colli di bottiglia nella pipeline: capisce esattamente dove va il tempo (preprocessing, inference, postprocessing, data transfer CPU/GPU).

PyTorch Profiler: Analisi Dettagliata della Pipeline
import torch
import torch.profiler as profiler
import cv2
import numpy as np
from ultralytics import YOLO

def profile_cv_pipeline(model_path: str,
                          video_source,
                          n_frames: int = 100,
                          output_dir: str = './profiler_logs') -> None:
    """
    Profila la pipeline CV con PyTorch Profiler.
    Genera log compatibili con TensorBoard per analisi visuale.

    Output: profiler_logs/  (aprire con: tensorboard --logdir profiler_logs)
    """
    model = YOLO(model_path)
    cap = cv2.VideoCapture(video_source)
    frame_count = 0

    with profiler.profile(
        activities=[
            profiler.ProfilerActivity.CPU,
            profiler.ProfilerActivity.CUDA,
        ],
        schedule=profiler.schedule(
            wait=5,      # Skip first 5 iterations (warmup variability)
            warmup=5,    # Warmup 5 iterations (profiler overhead)
            active=20,   # Profile 20 iterations
            repeat=2     # Repeat the cycle 2 times
        ),
        on_trace_ready=profiler.tensorboard_trace_handler(output_dir),
        record_shapes=True,   # Record tensor shapes
        profile_memory=True,  # Track memory allocations
        with_stack=True       # Include call stack
    ) as prof:

        while frame_count < n_frames:
            ret, frame = cap.read()
            if not ret:
                break

            with torch.profiler.record_function("preprocessing"):
                rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
                tensor = torch.from_numpy(rgb).float() / 255.0
                tensor = tensor.permute(2, 0, 1).unsqueeze(0)
                if torch.cuda.is_available():
                    tensor = tensor.cuda()

            with torch.profiler.record_function("inference"):
                with torch.no_grad():
                    results = model.predict(frame, verbose=False)

            with torch.profiler.record_function("postprocessing"):
                boxes = results[0].boxes
                n_det = len(boxes)

            prof.step()
            frame_count += 1

    cap.release()
    print(f"Profiling completato. Risultati in: {output_dir}")
    print(f"Avvia: tensorboard --logdir {output_dir}")

    # Stampa tabella top operazioni (utile senza TensorBoard)
    print(prof.key_averages().table(
        sort_by="cuda_time_total", row_limit=15
    ))


# Profiling semplice con timer manuale per produzioni senza TensorBoard
class PipelineProfiler:
    """Profiler leggero per monitoraggio continuo in produzione."""

    def __init__(self, window_size: int = 100):
        import collections
        self.window_size = window_size
        self.times: dict = {
            'preprocess': collections.deque(maxlen=window_size),
            'inference':  collections.deque(maxlen=window_size),
            'postprocess': collections.deque(maxlen=window_size),
        }

    def record(self, stage: str, duration_ms: float) -> None:
        if stage in self.times:
            self.times[stage].append(duration_ms)

    def report(self) -> dict:
        """Restituisce statistiche rolling degli ultimi N frame."""
        stats = {}
        for stage, times in self.times.items():
            if times:
                arr = np.array(times)
                stats[stage] = {
                    'mean_ms': float(np.mean(arr)),
                    'p50_ms':  float(np.percentile(arr, 50)),
                    'p95_ms':  float(np.percentile(arr, 95)),
                    'p99_ms':  float(np.percentile(arr, 99)),
                }
        return stats

    def print_report(self) -> None:
        stats = self.report()
        print("\n=== Pipeline Performance (last {self.window_size} frames) ===")
        for stage, s in stats.items():
            print(f"  {stage:12s}: mean={s['mean_ms']:.1f}ms  "
                  f"p95={s['p95_ms']:.1f}ms  p99={s['p99_ms']:.1f}ms")

6.2 OpenCV con Accelerazione CUDA

OpenCV supporta un modulo cuda (opencv-contrib-python compilato con CUDA) che accelera le operazioni di preprocessing fino a 10x su GPU NVIDIA. Particolarmente utile per resize, gaussian blur e color conversions in pipeline ad alta frequenza.

OpenCV CUDA: Preprocessing Accelerato su GPU
import cv2
import numpy as np
import torch

def check_opencv_cuda() -> dict:
    """Verifica disponibilità e configurazione di OpenCV CUDA."""
    info = {
        'opencv_version': cv2.__version__,
        'cuda_enabled': cv2.cuda.getCudaEnabledDeviceCount() > 0,
        'gpu_count': cv2.cuda.getCudaEnabledDeviceCount(),
    }

    if info['cuda_enabled']:
        info['gpu_name'] = cv2.cuda.printShortCudaDeviceInfo(0)

    return info


class CUDAPreprocessor:
    """
    Preprocessor OpenCV accelerato su GPU.
    Richiede: pip install opencv-contrib-python
    e compilazione OpenCV con CUDA support.

    Speedup tipico vs CPU: 5-10x per resize+cvtColor
    """

    def __init__(self, target_size: tuple = (640, 640)):
        self.target_size = target_size
        self.has_cuda = cv2.cuda.getCudaEnabledDeviceCount() > 0

        if self.has_cuda:
            # Pre-alloca stream CUDA per pipeline asincrona
            self.stream = cv2.cuda_Stream()
            # GPU matrix per evitare ri-allocazioni
            self.gpu_frame = cv2.cuda_GpuMat()
            self.gpu_rgb = cv2.cuda_GpuMat()
            self.gpu_resized = cv2.cuda_GpuMat()

    def preprocess_cuda(self, img_bgr: np.ndarray) -> np.ndarray:
        """
        Preprocessing su GPU: BGR->RGB + Resize + (opzionale) Gaussian blur.
        Returns: numpy array RGB normalizzato [0,1] float32
        """
        if not self.has_cuda:
            return self._preprocess_cpu(img_bgr)

        # Upload a GPU
        self.gpu_frame.upload(img_bgr, self.stream)

        # BGR -> RGB su GPU
        cv2.cuda.cvtColor(self.gpu_frame, cv2.COLOR_BGR2RGB,
                          self.gpu_rgb, stream=self.stream)

        # Resize su GPU (INTER_LINEAR e supportato in cuda)
        cv2.cuda.resize(self.gpu_rgb, self.target_size,
                        self.gpu_resized,
                        interpolation=cv2.INTER_LINEAR,
                        stream=self.stream)

        # Download da GPU (sincrono - necessario prima dell'inference PyTorch)
        result = self.gpu_resized.download(stream=self.stream)
        self.stream.waitForCompletion()

        return result.astype(np.float32) / 255.0

    def _preprocess_cpu(self, img_bgr: np.ndarray) -> np.ndarray:
        """Fallback CPU se CUDA non e disponibile."""
        rgb = cv2.cvtColor(img_bgr, cv2.COLOR_BGR2RGB)
        resized = cv2.resize(rgb, self.target_size, interpolation=cv2.INTER_LINEAR)
        return resized.astype(np.float32) / 255.0

    def preprocess_batch_cuda(self, frames: list[np.ndarray]) -> torch.Tensor:
        """
        Preprocessing batch su GPU.
        Converte lista di frame in un batch tensor pronto per inference.
        Massimizza throughput per pipeline multi-camera.
        """
        preprocessed = [self.preprocess_cuda(f) for f in frames]

        # Stack in batch tensor [B, C, H, W]
        batch = np.stack(preprocessed)  # [B, H, W, C]
        batch_tensor = torch.from_numpy(batch).permute(0, 3, 1, 2)

        if torch.cuda.is_available():
            batch_tensor = batch_tensor.cuda(non_blocking=True)

        return batch_tensor


# Benchmark: CPU vs CUDA preprocessing
def benchmark_preprocessing(n_frames: int = 500,
                              img_size: tuple = (1920, 1080)) -> None:
    """Confronta velocità preprocessing CPU vs CUDA."""
    import time

    # Genera frame sintetici
    frames = [np.random.randint(0, 255, (*img_size, 3), dtype=np.uint8)
              for _ in range(10)]

    preprocessor = CUDAPreprocessor(target_size=(640, 640))

    # Benchmark CPU
    t0 = time.perf_counter()
    for i in range(n_frames):
        f = frames[i % 10]
        preprocessor._preprocess_cpu(f)
    cpu_time = time.perf_counter() - t0

    # Benchmark CUDA (se disponibile)
    if preprocessor.has_cuda:
        t0 = time.perf_counter()
        for i in range(n_frames):
            f = frames[i % 10]
            preprocessor.preprocess_cuda(f)
        cuda_time = time.perf_counter() - t0

        print(f"Preprocessing {n_frames} frame ({img_size[1]}x{img_size[0]} -> 640x640):")
        print(f"  CPU:  {cpu_time:.2f}s  ({n_frames/cpu_time:.0f} FPS)")
        print(f"  CUDA: {cuda_time:.2f}s  ({n_frames/cuda_time:.0f} FPS)")
        print(f"  Speedup: {cpu_time/cuda_time:.1f}x")
    else:
        print("CUDA non disponibile, solo benchmark CPU")
        print(f"  CPU: {cpu_time:.2f}s  ({n_frames/cpu_time:.0f} FPS)")

7. Image Quality Assessment e Metriche di Frame

Prima di inviare un frame all'inference, vale la pena valutarne la qualità. Frame mossi, sovraesposti o con scarsa nitidezza producono false negative e riducono l'affidabilità del sistema. Le metriche PSNR e SSIM, tipicamente usate per la qualità della compressione, si applicano bene anche al frame filtering.

Frame Quality Assessment: Blur Detection, SSIM e Adaptive Threshold
import cv2
import numpy as np
from dataclasses import dataclass

@dataclass
class FrameQuality:
    """Metriche di qualità per un singolo frame."""
    blur_score: float      # Varianza Laplaciano (alto = nitido)
    brightness: float      # Luminosita media [0, 255]
    contrast: float        # Deviazione standard luminosita
    is_valid: bool         # Frame accettabile per inference?
    reject_reason: str     # Motivo del rifiuto ('', 'blur', 'dark', ecc.)

class FrameQualityFilter:
    """
    Filtra frame di bassa qualità prima dell'inference.
    Riduce falsi negativi in sistemi di sorveglianza.
    """

    def __init__(self,
                 blur_threshold: float = 100.0,    # Laplacian variance
                 brightness_min: float = 30.0,
                 brightness_max: float = 220.0,
                 contrast_min: float = 15.0):
        self.blur_threshold = blur_threshold
        self.brightness_min = brightness_min
        self.brightness_max = brightness_max
        self.contrast_min = contrast_min

    def assess(self, frame_bgr: np.ndarray) -> FrameQuality:
        """Valuta qualità del frame."""
        gray = cv2.cvtColor(frame_bgr, cv2.COLOR_BGR2GRAY)

        # Blur detection: varianza del Laplaciano
        # Un frame nitido ha bordi marcati -> alta varianza
        laplacian_var = cv2.Laplacian(gray, cv2.CV_64F).var()

        # Luminosita e contrasto
        brightness = float(np.mean(gray))
        contrast = float(np.std(gray))

        # Valutazione
        reject_reason = ''
        if laplacian_var < self.blur_threshold:
            reject_reason = f'blur (var={laplacian_var:.1f})'
        elif brightness < self.brightness_min:
            reject_reason = f'too_dark (mean={brightness:.1f})'
        elif brightness > self.brightness_max:
            reject_reason = f'overexposed (mean={brightness:.1f})'
        elif contrast < self.contrast_min:
            reject_reason = f'low_contrast (std={contrast:.1f})'

        return FrameQuality(
            blur_score=laplacian_var,
            brightness=brightness,
            contrast=contrast,
            is_valid=(reject_reason == ''),
            reject_reason=reject_reason
        )

    def filter_batch(self, frames: list[np.ndarray]) -> tuple[list, list]:
        """
        Filtra una batch di frame.
        Returns: (valid_frames, rejected_frames_with_reason)
        """
        valid = []
        rejected = []

        for frame in frames:
            quality = self.assess(frame)
            if quality.is_valid:
                valid.append(frame)
            else:
                rejected.append((frame, quality.reject_reason))

        return valid, rejected


def compute_psnr(original: np.ndarray, compressed: np.ndarray) -> float:
    """
    Peak Signal-to-Noise Ratio tra immagine originale e compressa.
    PSNR > 40 dB = ottima qualità; < 20 dB = bassa qualità percettibile.
    """
    mse = np.mean((original.astype(float) - compressed.astype(float)) ** 2)
    if mse == 0:
        return float('inf')
    max_pixel = 255.0
    return 20 * np.log10(max_pixel / np.sqrt(mse))


def compute_ssim(img1: np.ndarray, img2: np.ndarray) -> float:
    """
    Structural Similarity Index (SSIM) tra due immagini grayscale.
    Range: [-1, 1], dove 1 = identiche, 0 = non correlate.
    Più fedele alla percezione umana rispetto a MSE/PSNR.
    """
    gray1 = cv2.cvtColor(img1, cv2.COLOR_BGR2GRAY).astype(float)
    gray2 = cv2.cvtColor(img2, cv2.COLOR_BGR2GRAY).astype(float)

    C1 = (0.01 * 255) ** 2  # costante stabilità
    C2 = (0.03 * 255) ** 2

    mu1, mu2 = gray1.mean(), gray2.mean()
    sigma1 = gray1.std()
    sigma2 = gray2.std()
    sigma12 = np.mean((gray1 - mu1) * (gray2 - mu2))

    numerator = (2 * mu1 * mu2 + C1) * (2 * sigma12 + C2)
    denominator = (mu1**2 + mu2**2 + C1) * (sigma1**2 + sigma2**2 + C2)

    return float(numerator / denominator)


# Utilizzo in pipeline con motion gating intelligente
class SmartMotionGate:
    """
    Combina background subtraction + SSIM per gating intelligente.
    Evita sia di inferire su frame identici (statica) sia su frame corrotti.
    """

    def __init__(self, ssim_change_threshold: float = 0.95):
        self.subtractor = cv2.createBackgroundSubtractorMOG2(
            history=200, varThreshold=40, detectShadows=False
        )
        self.quality_filter = FrameQualityFilter()
        self.ssim_threshold = ssim_change_threshold
        self.prev_frame = None

    def should_infer(self, frame: np.ndarray) -> tuple[bool, str]:
        """
        Decide se inferire su questo frame.
        Returns: (should_infer, reason)
        """
        # 1. Quality check
        quality = self.quality_filter.assess(frame)
        if not quality.is_valid:
            return False, f"low_quality: {quality.reject_reason}"

        # 2. Motion detection (veloce)
        fg_mask = self.subtractor.apply(frame)
        motion_ratio = np.sum(fg_mask > 0) / fg_mask.size

        if motion_ratio < 0.005:  # meno dello 0.5% dei pixel in movimento
            return False, "no_motion"

        # 3. SSIM check (rileva cambiamenti strutturali, non solo rumore)
        if self.prev_frame is not None:
            ssim = compute_ssim(frame, self.prev_frame)
            if ssim > self.ssim_threshold:
                return False, f"scene_static (ssim={ssim:.3f})"

        self.prev_frame = frame.copy()
        return True, "ok"

8. Best Practices e Performance

Performance Tipiche: YOLO26m in Pipeline OpenCV con CUDA Preprocessing

Hardware FPS (640x640) Latenza Ottimizzazione
NVIDIA A100 ~220 FPS ~4.5ms TensorRT FP16
NVIDIA RTX 4090 ~180 FPS ~5.6ms TensorRT FP16
NVIDIA RTX 3080 ~120 FPS ~8.3ms ONNX Runtime
CPU Intel i9 (ONNX) ~18 FPS ~55ms OpenVINO
Raspberry Pi 5 ~3 FPS ~330ms YOLOv8n INT8

Ottimizzazioni Performance

  • Leggi in thread separato: Non bloccare il loop di inference con I/O della camera. Usa ThreadedVideoCapture per massimizzare l'utilizzo GPU.
  • BGR->RGB una volta sola: Non convertire ad ogni chiamata. Converti alla lettura e mantieni RGB per tutto il pipeline.
  • torch.no_grad() sempre in inference: Disabilita il grafo computazionale di autograd durante l'inference: -30% memoria, +10% velocità.
  • Batch inference: Se hai più stream video, accumula frame e inferisci in batch. Il throughput GPU scala quasi linearmente con il batch size.
  • TensorRT per produzione: Su hardware NVIDIA, esporta sempre in TensorRT per la massima velocità. YOLOv8m: da 50 a 180 FPS con TensorRT FP16.
  • Background subtraction come gating: In scene con poco movimento, esegui l'inference DL solo sui frame dove MOG2 rileva movimento. Risparmia il 60-70% di compute.
  • Frame quality filter: Scarta frame mossi (blur score < 100) e sottoesposti prima dell'inference. Riduce i falsi negativi e migliora la precision del sistema.
  • SSIM per scene statiche: Se due frame consecutivi hanno SSIM > 0.95, la scena non e cambiata. Non rieseguire l'inference, riusa i risultati precedenti.
  • OpenCV CUDA per preprocessing: Se hai una GPU NVIDIA e opencv-contrib compilato con CUDA, il preprocessing (resize, cvtColor) e 5-10x più veloce su GPU.

Errori Comuni da Evitare

  • Non effettuare warmup del modello: La prima inference e sempre più lenta (JIT compilation, CUDA initialization). Esegui 3-5 inference dummy prima di misurare le performance.
  • Dimenticare model.eval(): In modalità train, i layer Dropout e BatchNorm si comportano diversamente. Sempre chiamare model.eval() prima dell'inference.
  • frame.copy() assente nell'annotazione: Non annotare direttamente il frame originale se lo stai anche usando per l'inference. Usa sempre frame.copy().
  • Non rilasciare VideoCapture: Ogni cv2.VideoCapture aperto deve essere rilasciato con cap.release(). Usa context manager o try/finally.
  • RTSP senza reconnect logic: Le connessioni RTSP si interrompono. Ogni camera reader deve avere retry logic con backoff esponenziale.

Conclusioni

Abbiamo costruito una pipeline CV completa che integra OpenCV e PyTorch/YOLO, coprendo ogni layer di un sistema production-ready:

  • OpenCV per acquisizione, preprocessing, postprocessing e visualizzazione
  • Threading per acquisizione video non bloccante che massimizza l'utilizzo GPU
  • Pipeline production-ready con logging strutturato, alerting e salvataggio video
  • Multi-camera con batch inference e auto-reconnect RTSP per scenari surveillance
  • Background subtraction (MOG2) e Smart Motion Gate per ridurre il compute fino al 70%
  • PyTorch Profiler per identificare esattamente i colli di bottiglia
  • OpenCV CUDA per preprocessing accelerato GPU (5-10x vs CPU)
  • Frame Quality Assessment per filtrare frame corrotti prima dell'inference
  • Benchmark performance su hardware reale: da A100 (220 FPS) a Raspberry Pi (3 FPS)

Prova Questi Strumenti

Strumenti gratuiti correlati a questo argomento.

Commenti

Caricamento commenti...

Accedi per commentare

Discuti questo articolo nella community

Unisciti al gruppo Telegram per discutere con altri sviluppatori, fare domande e condividere le tue esperienze.

Ti è piaciuto questo articolo?

Esplora altri contenuti sul blog o scopri i miei progetti
